DisclaimerThis is just an amateur pedal with no intention for profit or to infringe any trademark.
Tube Screamer is a trademark of Hoshino Gakki Co.
Nutube is a trademark of KORG INC.
This pedal is not for sale. If you want to buy a similar pedal I recommend you Ibanez NTS Screamer.
AssemblyNude PCB before assembly, components side:
PCB with SMD components assembled:
PCB fully assembled connectors and potentiometers side. Tests without enclosure were quite noisy:
PCB fully assembled connectors and potentiometers side:
PCB fully assembled on SMD components side:
Guitar pedal fully assembled verified and ready for tests:
Source files for Eagle schematics, BoM and layout as well as FreeCAD 3D files can be found on github:
Chords tests:Solo test:
NuTube Overdrive Test playlist video with Stone Roses solo, bluesy solo and chords:
